Vertical Honing Machine HDHJ5089 Multiplex Sequential Precision Machining Honing Machine
Product Details
| Brand Name: | HD | Model Number: | HDHJ5089 |
|---|---|---|---|
| Key Word: | Vertical Honing And Reaming Machine | ||
| Highlight |
HDHJ5089 Vertical Honing Machine,Precision Machining Vertical Honing Machine,Multiplex Sequential Vertical Honing Machine |
||
Product Description
Product Description:
Multi-station sequential honing machine adopts series multi-station design, each station is equipped with an independent honing head, which can adjust the feed amount independently according to the workpiece size and tolerance requirements, and the workpiece is automatically transmitted between each station to achieve continuous and efficient precision honing processing. The equipment has the advantages of high production efficiency, strong processing flexibility and high degree of automation, and is widely used in precision parts processing in automotive, aerospace and other industries.
Product Features:
Made of high-strength pregnant cast iron, long-lasting and reliable precision.High speed rotary table.
Motion system adopts ball screw and linear guide. Prepared to add automatic line interface, convenient for the later access of automated robots.
It can process the inner hole of cast iron, soft steel, hardened steel, copper, aluminium, cemented
carbide, glass, ceramics and other kinds of parts.
Suitable for automobile engine cylinder block cylinder sleeve, connecting rod, gear, shifting fork,
oil pump nozzle, bearing, valve sleeve, mould, motorbike parts, industrial sewing machine
parts, aerospace parts, air conditioning and refrigeration, hydraulic and pneumatic parts.
|
Main technical specifications
|
Unit
|
HDHJ5089
|
|
Machine features
|
|
8-axis 9-station
|
|
Number of spindle
|
Pcs
|
8
|
|
Number of worktable transposition
|
Pcs
|
9
|
|
Worktable positioning method
|
|
splitter
|
|
Worktable drive power
|
kw
|
0.37
|
|
Worktable diameter
|
mm
|
690
|
|
Worktable rotation time for one station
|
s
|
1.1
|
|
Distance from spindle end face to table surface
|
mm
|
760(1000)
|
|
Main body weight
|
T
|
2.6
|
|
Dimension of mainframe(L*W*H)
|
mm
|
1725×1260×2600
|
|
Max. honing diameter
|
mm
|
50 (60 optional)
|
|
Max. honing depth
|
mm
|
200(230)
|
|
Spindle drive type
|
|
servo motor
|
|
Max. spindle speed
|
r/min
|
600
|
|
Spindle reciprocating drive power
|
kw
|
3.1 |
|
Max. spindle travel
|
mm
|
650
|
|
Max. spindle reciprocating speed
|
m/min
|
20
|
|
Control system
|
|
Nanjing CNC/Siemens PLC
|
Industry application:
OUR Service:
- Ensure you receive a high quality machine
- 1. Every parts need be inspected
- 2. Over 100 production process control
- 3. Over 200 inspection items
- 4. Sample processing of each machine
- 5. 72 hours trial run before delivery
Why Choose Us:
- ◆ Top quality sense, customers' requests come first
- ◆ 30 years + R & D history, the company was founded in 1993
- ◆ High-tech manufacturer with research anddesign capacity
- ◆ Stable and mature supplying system
- ◆ Young active sales and engineers for instant services(24 hours online)
- ◆ Upgrading on mechanism according to ergonomics and easy maintenance
- ◆ Our structure design principle: easy maintenance & installation, low cost maintenance, not affect production
About Us:
Shanghai HD M&E Tech Co., Ltd is located in Shanghai, China. We specialize in CNC lathe, vertical machining center, horizontal machining center, gantry machining center, five-axis machining center, turn-milling center and various other CNC equipment. We have more than 200 kinds of machine tools. The quality and technology of products have reached the international advanced level.
Our factory has over 80 years’ history of manufacturing machine tools. The first lathe, drilling machine and boring machine were all born here. They have been one of the leader of China's Machine Tool industry and the largest machine tool manufacture in China. Machine tool products cover automobiles, aviation, new energy, construction machinery, ships, pump valves, bearings, 3C electronics, molds and other industries. We take the mission of providing the machine tools with leading technology, high quality and good service to our customers all over the world!
FAQ:
Q1. Are you a trade company or manufacturing company?
We are a manufacturing company.
Q2. What's your main products of your company?
We specialized in all kinds of machines, such as CNC Lathe, CNC Milling Machine, Vertical Machining Center,Conventional Lathe, Drilling Machine, Radial Drilling Machine, and so on.
Q3. Can you provide customized machine or SPM (Special purpose machine)?
Yes, we provide Smart CNC solutions for our customer in order to increase efficiency.
Q4: What's your warranty terms?
We will supply a replacement for parts that prove to be defective for a period of 12 months,
starting on the machine's bill of lading date.
Q5. What is the services?
Pr-sales:Customized solutions, planning and design;One-to-one service
After sales:7 days 24 hours on line service, Remote guidance of installation, docking with customer software system
Q6: Why choose your company?
Products from the development, design, manufacture, assembly of the entire production process are
carried out between plants with a complete production chain which is your most reliable guarantee.
Q7: Can your company send the technical personnel to our company and direct our workers overseas?
We can supply this kind of service. When the machines arrive the buyer's installation site, we can timely send mechanical and electrical engineers to install according to the buyer's schedule. All these can be quoted and list in the contract. The seller will cooperate with the buyer to deal with visa and installation preparation before going abroad.
Q8: What's the Payment Terms?
T/T 30% initial payment when order, 70% balance payment before shipment. irrevocable letter ofcredit at sight
Product Highlights
Vertical Honing Machine HDHJ5089 features 8-axis 9-station multiplex sequential design with independent honing heads for continuous precision machining. Made of high-strength cast iron with ball screw/linear guide motion system, it processes various materials including steel, ceramics, and carbide. Ideal for automotive, aerospace, and hydraulic components with high automation and efficiency.
