Place of Origin:
CHINA
Brand Name:
SMTCL
Certification:
CE ISO certification
Model Number:
HTC 30H
Video
Video
Video
Product Description:
Product Features:
Product Details:
|
Project
|
Unit
|
HTC 30H
|
|
Max. cutting dia.
|
mm
|
Φ300
|
|
Max.cutting length
|
mm
|
500
|
|
Max. swiming dia.over bed
|
mm
|
Φ420
|
|
Max. swiming dia.on slide
|
mm
|
Φ280
|
|
Spindle
|
|
|
|
Spindle nose model
|
|
A2-6
|
|
Front bearing inner dia.
|
mm
|
100
|
|
Spindle taper and hole size
|
|
1:20;Φ70
|
|
Dia. of spindle hole
|
|
Φ65
|
|
Max.bar dia.
|
mm
|
Φ50
|
|
Standard chuck dia.
|
inch
|
8
|
|
Spindle speed range
|
r/min
|
4500
|
|
Rated spindle torque
|
N·m
|
100(769r/min)
|
|
Spindle Max. torque
|
N·m
|
180(576r/min)
|
|
Main motor output power continuous/15 min.
|
kW
|
9/11
|
|
X/Z axis
|
|
|
|
X/Z axis rapid movement
|
m/min
|
30
|
|
X axis travel
|
mm
|
160
|
|
Z axis travel
|
mm
|
560
|
|
Tailstock
|
|
|
|
Tailstock travel
|
mm
|
300
|
|
Tailstock drive method
|
|
Saddle drag
|
|
Tailstock sleeve travel
|
mm
|
100
|
|
Tailstock sleeve dia.
|
mm
|
Φ100
|
|
Tailstock taper hole taper
|
Morse
|
MT-5
|
|
Turret
|
|
|
|
Turret typle
|
|
Horizontal 8-station servo turret
|
|
Center height
|
mm
|
80
|
|
Turret indexing repeat positioning accuracy
|
Sec.
|
±1.6
|
|
If could choose tool nearby
|
|
yes
|
|
Others
|
|
|
|
Distance between spindle center and floor
|
mm
|
936
|
|
Machine tool net weight
|
kg
|
3500
|
|
Total electrical capacity
|
KVA
|
23
|
|
Overall dimensions(LxWxH)
|
mm
|
2295×1680×1650
|
|
Note: The parameters provided in the table are for reference only. If there is any change, please refer to the actual product.
|
||
OUR Service:
1. Assemble and debug before delivery
2. Respond within 24 hours and proceed to deal with the problem.
3. 1 year free repair service (no-human damage only).
4. Overall warehousing solution provided
