SMTCL Tornos Para Metal Conventional Lathe CA6150A 2000mm Ordinary Horizontal Manual Lathe Machine
Product Details
| Brand Name: | SMTCL | Model Number: | CA6150A/6250A |
|---|---|---|---|
| CNC Or Not: | Manual | Key Word: | Conventional Lathe Machine |
| Max.swing Dia Over Bed: | 500mm | Max.swing Dia Over Carriage: | 300mm |
| Width Of Bed: | 400mm | Spindle Bore: | 52mm |
| Highlight |
Tornos Para Metal Conventional Lathe,2000mm Horizontal Ordinary Lathe,Ordinary Horizontal Manual Lathe Machine |
||
Product Description
Product Description:
The CA6140A is a common - type lathe. It can turn internal and external cylindrical surfaces, conical surfaces, etc., and process various threads. With a maximum swing diameter of 400mm on the bed, the spindle speed ranges from 11 to 1600r/min. It has high - stiffness bed and is suitable for processing steel, cast iron, etc.
Product Features:
1,Novel appearance
The appearance design of the machine tool integrates the ergonomic concept into the mature machine structure, enhances the operation, uses the striking red and gray stamping parts, and the overall appearance is beautiful.
2,Complete specifications
CA series products have complete specifications and a wide range of categories. Including straight bed lathe, saddle bed lathe and large bore lathe.
3,Complete functions
CA series lathe can bear a variety of materials end, inside and outside E1 column, cone and other rotating surface turning processing. More accurate processing of a variety of metric, imperial, modular, diameter pitch threads. In addition, drilling, hairpin holes, pulling oil guns and other work can also be easily qualified.
4,Excellent performance
The 40A series ordinary lathe is equipped with a large diameter spindle front bearing and has a wider bed span than similar products, achieving a higher structural difference and achieving new levels of performance.
Product Details:
OUR Service:
Ensure you receive a high quality machine
1. Every parts need be inspected
3. Over 200 inspection items
4. Sample processing of each machine
5. 72 hours trial run before delivery
◆ 30 years + R & D history, the company was founded in 1993
◆ High-tech manufacturer with research anddesign capacity
◆ Stable and mature supplying system
◆ Young active sales and engineers for instant services(24 hours online)
◆ Upgrading on mechanism according to ergonomics and easy maintenance
◆ Our structure design principle: easy maintenance & installation, low cost maintenance, not affect production
FAQ:
Q1. Are you a trade company or manufacturing company?
starting on the machine's bill of lading date.
Pr-sales:Customized solutions, planning and design;One-to-one service
After sales:7 days 24 hours on line service, Remote guidance of installation, docking with customer software system
carried out between plants with a complete production chain which is your most reliable guarantee.
