Place of Origin:
CHINA
Brand Name:
SMTCL
Certification:
CE ISO certification
Model Number:
HMC 80Q
Video
Video
Product Description:
Product Features:
1,High stability structure
◆ Inverted T-shaped integrally cast bed
◆ Y-axis motor base and column are casted together
◆ Thermally symmetrical spindle
| Item | Unit | HMC 80Q |
| Work table | ||
| Worktable size | mm | 800*800 |
| Worktable capacity | kg | 2000 |
| Number of worktable | pcs | 1(2) |
| Working range | ||
| X axis travel | mm | 1350 |
| Y axis travel | mm | 1100 |
| Z axis travel | mm | 1100 |
| B-axis indexing | 1° ×360 | |
| Max. rotation diameter of workpiece | mm | Φ1350 |
| Distance from spindle nose to worktable center | mm | 1300 Max |
| Distance from spindle nose to worktable center | mm | 200 Min |
| Distance between s p i n d l e n o s e t o worktable surface | mm | 1100 Max |
| Distance between s p i n d l e n o s e t o worktable surface | mm | 0 Min |
| Spindle | ||
| Spindle taper (7: 24) | BT50 | |
| Maximum speed | rpm | 6000 |
| Spindle motor power (continuous/S2) | kw | 15/18.5 |
| Maximum output torque(continuous/S2) | mm | 433/713(15min) |
| Tool magazine | ||
| Tool magazine capacity | PCS | 24 |
| Max. tool length | Mm | 500 |
| Max. tool weight | kg | 15 |
| Max. tool diameter full/empty | mm | Φ110/Φ220 |
| Tool change time(T-T) | s | 4.3 |
| Feed | ||
| Maximum cutting feed speed(X/Y/Z) | Mm/min | 1-24000 |
| Rapid traverse(X/Y/Z) | M/min | 24 |
| Positioning accuracy | ||
| X/Y/Z axis | mm | 0.01 |
| B axis(1° X360) | ‘’ | 10 |
| Repetitive positioning accuracy | ||
| X/Y/Z axis | mm | 0.008 |
| B axis(1° ×360) | ‘’ | 3 |
| Overall dimension(LxWxH) | mm | 4300*3400*3600 |
| Floor space | mm | 5100*5000 |
Industry application:
OUR Service:
1. Assemble and debug before delivery
