SMTCL Gang Tool Slant Bed CNC Lathe CHK46 Automatic Gang Type Lathe With Bar Feeder

Brand Name: SMTCL
Model Number: CHK46
Place of Origin: China
Certification: ISO certification
Minimum Order Quantity: 1 Set
Supply Ability: 50 sets per month
Tags

CNC Lathe Machine

High Precision Horizontal CNC Lathe

CNC Turning Center

Product Details

Product Name: Gang Tool Slant Bed CNC Lathe Swing Over Bed: 400mm
Max.turning Diameter: 250mm Max. Machining Length: 350mm
The Maximum Bar Through Hole Diameter: 56mm Spindle Nose: A2-5
Motor Power Of Spindle: 7.5/11 Kw
Highlight

4000rpm CNC Turning Lathe Machine Center

,

11 Kw CNC Lathe Machines

,

Hardware Processing CNC Lathe Machines

Product Description

SMTCL Gang Tool Slant Bed CNC Lathe CHK46 Automatic Gang Type Lathe With Bar Feeder 0

Product Description:

Gang Tool Slant Bed CNC Lathe Machine CHK46 Automatic Gang Type Lathe Machine With Bar Feeder
CHK46 has outstanding performance, with the design of gang tool post being its prominent highlight.
The gang tool post has a compact layout, enabling quick and precise tool changes, which greatly shortens the auxiliary processing time and effectively improves production efficiency. The machine tool is equipped with a high-precision spindle that has strong and stable power, ensuring machining accuracy and surface quality. The machine body has strong rigidity and excellent anti-vibration performance, and it is suitable for precision machining of various materials. It is easy to operate and widely used in the manufacturing field of small precision parts, and it is a powerful assistant for enhancing the competitiveness of enterprises.

Product Features:

CHK46 has the following three remarkable features:

Firstly, it is equipped with a high-precision gang tool post. Tools can be changed quickly and positioned precisely, which greatly improves the machining efficiency and accuracy.
Secondly, the machine tool adopts a high-rigidity body design with excellent anti-vibration performance. It can ensure the stability of machining even during high-speed cutting and guarantee the machining quality of workpieces.
Thirdly, it is equipped with an advanced CNC system. The operation is simple and intuitive, and it can realize the programming of complex processing techniques to meet diverse processing requirements. It is suitable for the efficient production of precision parts.
Product details:

SMTCL Gang Tool Slant Bed CNC Lathe CHK46 Automatic Gang Type Lathe With Bar Feeder 1SMTCL Gang Tool Slant Bed CNC Lathe CHK46 Automatic Gang Type Lathe With Bar Feeder 2

SMTCL Gang Tool Slant Bed CNC Lathe CHK46 Automatic Gang Type Lathe With Bar Feeder 3SMTCL Gang Tool Slant Bed CNC Lathe CHK46 Automatic Gang Type Lathe With Bar Feeder 4

Product Paramenters:
Item
Unit
CHK46
Max. turning diameter
mm
Φ250
Max. turning length
mm
350
Max.swing diameter over bed
mm
Φ400
Max.swing diameter over cross slide
mm
Φ100
Spindle
Type of spindle nose

A2-5
Inner diameter of front bearing
mm
Φ90
Taper of spindle bore

Φ90
Spindle bore

Morse 6#
Max. through bar diameter
mm
Φ56
Max.dia.of bar
mm
Φ45
Max. bore diameter of the collet
mm
Φ46
Max. spindle speed
r/min
4000
Spindle rated torque
Nm
72
Max. spindle torque
Nm
105
Main motor output power continuous /30 minutes
kW
7.5/11
X/Z axis
X/Z rapid traverse
m/min
24
X axis travel
mm
430
Z axis travel
mm
430
Turret
Turret form

Gang type tool post
Center height of the boring tool holder
mm
52
Outer circle tool holder
mm
20×20
Double-sided outer circle tool holder
mm
20×20
Face tool holder
mm
20×20
Boring tool holder
mm
Φ25
Cooling and chip removal
Chip removal form

Chip conveyor box
Other
Distance from spindle center to bed bottom
mm
1060
Machine net weight
kg
2250
Total power supply capacity
kVA
16
Overall dimensions (Length X width X height)
mm
2250×1350×1850
Machine tool accuracy
Inspection items
Factory Standard
Processing accuracy
IT6
Roundness of workpiece
0.005mm
Cylindricity of workpiece
0.015 mm / 110 mm
Flatness of workpiece
0.015mm/ Ф 130mm
Surface roughness of workpiece
Ra 1.6 μm​
Positioning accuracy
X-axis
0.01mm
Z-axis
0.01mm
Repeat positioning Accuracy
X-axis
0.006 mm
Z-axis
0.006 mm

Industry application:

SMTCL Gang Tool Slant Bed CNC Lathe CHK46 Automatic Gang Type Lathe With Bar Feeder 5

OUR Service:

Ensure you receive a high quality machine
1. Every parts need be inspected
2. Over 100 production process control
3. Over 200 inspection items
4. Sample processing of each machine
5. 72 hours trial run before delivery

Why Choose Us:
◆ Top quality sense, customers' requests come first
◆ 30 years + R & D history, the company was founded in 1993
◆ High-tech manufacturer with research anddesign capacity
◆ Stable and mature supplying system
◆Young active sales and engineers for instant services(24 hours online)
◆ Upgrading on mechanism according to ergonomics and easy maintenance
◆ Our structure design principle: easy maintenance & installation, low cost maintenance, not affect production
About Us:
SMTCL Gang Tool Slant Bed CNC Lathe CHK46 Automatic Gang Type Lathe With Bar Feeder 6
Welcome to visit us!
Shanghai HD M&E Tech Co., Ltd is located in Shanghai, China. We specialize in CNC lathe, vertical machining center, horizontal machining center, gantry machining center, five-axis machining center, turn-milling center and various other CNC equipment. We have more than 200 kinds of machine tools. The quality and technology of products have reached the international advanced level.
Our factory has over 80 years’ history of manufacturing machine tools. The first lathe, drilling machine and boring machine were all born here. They have been one of the leader of China's Machine Tool industry and the largest machine tool manufacture in China. Machine tool products cover automobiles, aviation, new energy, construction machinery, ships, pump valves, bearings, 3C electronics, molds and other industries. We take the mission of providing the machine tools with leading technology, high quality and good service to our customers all over the world!
Our Factory:
SMTCL Gang Tool Slant Bed CNC Lathe CHK46 Automatic Gang Type Lathe With Bar Feeder 7

FAQ:

Q1. Are you a trade company or manufacturing company?

We are a manufacturing company.
Q2. What's your main products of your company?
We specialized in all kinds of machines, such as CNC Lathe, CNC Milling Machine, Vertical Machining Center,Conventional Lathe, Drilling Machine, Radial Drilling Machine, and so on.
Q3. Can you provide customized machine or SPM (Special purpose machine)?
Yes, we provide Smart CNC solutions for our customer in order to increase efficiency.
Q4: What's your warranty terms?
We will supply a replacement for parts that prove to be defective for a period of 12 months,
starting on the machine's bill of lading date.
Q5. What is the services?
Pr-sales:Customized solutions, planning and design;One-to-one service
After sales:7 days 24 hours on line service, Remote guidance of installation, docking with customer software system
Q6: Why choose your company?
Products from the development, design, manufacture, assembly of the entire production process are
carried out between plants with a complete production chain which is your most reliable guarantee.
Q7: Can your company send the technical personnel to our company and direct our workers overseas?
We can supply this kind of service. When the machines arrive the buyer's installation site, we can timely send mechanical and electrical engineers to install according to the buyer's schedule. All these can be quoted and list in the contract. The seller will cooperate with the buyer to deal with visa and installation preparation before going abroad.
Q8: What's the Payment Terms?
T/T 30% initial payment when order, 70% balance payment before shipment. irrevocable letter ofcredit at sight
